HD 35-A

    Thương hiệu: RCF

    • 132 dB Max SPL
    • 1400 Watts 2-way peak power
    • DSP Processing with FiRPHASE
    • 1.4” Titanium Compression Driver, 3.0” v.c. Neodimium
    • 15” Woofer, high power
    • 800 Hz crossover point for perfect vocal reproduction
    • 90°x60°, wide dispersion constant directivity horn
    • Silent Fanless Class-D Amplifier
    Danh mục:



      Acoustical specifications
      FREQUENCY RESPONSE:
      45 Hz ÷ 20000 Hz



      HORIZONTAL COVERAGE ANGLE:
      90°
      MAX SPL @ 1M:
      132 dB
      VERTICAL COVERAGE ANGLE:
      60°
      Transducers
      COMPRESSION DRIVER:
      1.4”, 3.0” v.c
      WOOFER:
      15”, 3.0” v.c
      Power section
      TOTAL POWER:
      1400 W Peak, 700 W RMS



      HIGH FREQUENCIES:
      400 W Peak, 200 W RMS
      LOW FREQUENCIES:
      1000 W Peak, 500 W RMS



      COOLING:
      Convection



      CONNECTIONS:
      Powercon IN/OUT
      Physical specifications

      CABINET/CASE MATERIAL:
      PP Composite
      HARDWARE:
      1 x M10 top, 1 x M10 bottom, 2 x M10 side
      HANDLES:
      1 Top, 2 Side


      POLE MOUNT/CAP:
      Yes
      GRILLE:
      Steel



      COLOR:
      Black
