HDL 30-A
Thương hiệu : RCF
- 2200W Two Way Amplifier
- 137 dB Max SPL
- 48 kHz, 32 bit DSP processing
- 1.4″ Titanium Compression Driver, 4.0″ voice coil
- 2 x 10″ Neodymium Woofers, 2.5″ voice coil
- Exclusive FiRPHASE technology on-board
- RDNet Control and Management
- 680 Hz Crossover Point
| Acoustical specifications |
FREQUENCY RESPONSE:
50 Hz ÷ 20000 Hz
HORIZONTAL COVERAGE ANGLE:
100°
|
MAX SPL @ 1M:
137 dB
VERTICAL COVERAGE ANGLE:
15°
|
| Transducers |
COMPRESSION DRIVER:
1 x 1.4” neo, 4.0” v.c
|
WOOFER:
2 x 10” neo, 2.5” v.c
|
| Power section |
TOTAL POWER:
2200 W Peak, 1100 W RMS
HIGH FREQUENCIES:
600 W Peak, 300 W RMS
|
LOW FREQUENCIES:
1600 W Peak, 800 W RMS
COOLING:
Forced
CONNECTIONS:
Powercon IN/OUT
|
| Physical specifications |
CABINET/CASE MATERIAL:
PP Composite
HARDWARE:
Array fittings
HANDLES:
2 Side
|
GRILLE:
Steel
COLOR:
Black
|
