The ART 745-A MK4 is the flagship speaker in its category. The titanium dome, 4.0” voice coil neodymium compression driver offers a unique vocal clarity and sound projection. The 15” neodymium woofer offers an extremely linear response and a precise, deep low frequency control. The transducers are produced using the most advanced assembly technologies. The amplifier delivers 1400 watts and is controlled by a DSP that takes care of crossover, equalisation, phase control, soft limiting and speaker protections
| Acoustical specifications |
FREQUENCY RESPONSE:
45 Hz ÷ 20000 Hz
HORIZONTAL COVERAGE ANGLE:
90°
|
MAX SPL @ 1M:
133 dB
VERTICAL COVERAGE ANGLE:
60°
|
| Transducers |
COMPRESSION DRIVER:
1 x 1.4” neo, 4.0” v.c
|
WOOFER:
15” neo, 3.5” v.c
|
| Power section |
TOTAL POWER:
1400 W Peak, 700 W RMS
HIGH FREQUENCIES:
400 W Peak, 200 W RMS
|
LOW FREQUENCIES:
1000 W Peak, 500 W RMS
COOLING:
Convection
CONNECTIONS:
VDE
|
| Physical specifications |
CABINET/CASE MATERIAL:
PP Composite
HARDWARE:
2 x M10
HANDLES:
1 Top, 2 Side
|
POLE MOUNT/CAP:
Yes
GRILLE:
Steel
COLOR:
Black
|
